4-72 Impeller rov qab nkhaus hlau Stainless muaj chaw dim pa Centrifugal Blower kiv cua cia muag

4-72 Impeller rov qab nkhaus hlau Stainless muaj chaw dim pa Centrifugal Blower kiv cua cia muag

4-72 thaum centrifugal tau kev cua thiab lwm yam roj tsis-hypergolic, txawm rau tib neeg, cev tsis-corrosive mus hlau khoom tawg yooj yim.

Xa kev nug

Kev xa khoom sai
Quality Assurance
24/7 Kev Pabcuam Cov Neeg Siv Khoom

Khoom Taw qhia

4-72 thaum centrifugal tau kev cua thiab lwm yam roj tsis-hypergolic, txawm rau tib neeg, cev tsis-corrosive mus hlau khoom tawg yooj yim. B4-72 yog tsim rau cov chaw dim pa roj inflammable thiab neeg tsis mloog hais. Cov nplaum tsis tau hauv qhov roj, qhov uas muaj plua tshauv thiab nyuab hais yuav tsum tsis pub tshaj 150mg/m³, pa sov yuav tsis pub tshaj 80 degree Celsius. Nws muaj kev kawm suab pneumatic. Yog li ntawd nws ua nta xws li balanced khiav, me ntsis kev co efficiency siab, lub neej ntev, li ntawd tseem nyob muaj feem xyuam rau cov cua hauv tsev, pa-txauv tso nyob hauv lub mining thiab muaj qhauj, loj-loj architectures, guesthouses, hauv cov khw, etc.

F4-72 series no los tiv thaiv corrosion thaum centrifugal. Cov khoom no fiberglass siv tam yas los yog stainless hlau. Nws yuav siv kev cov roj corrosive. Cov kev kawm thiab cov plahaum loj yog tib yam li 4-72 kiv cua.

Tsis tag ntiav.	Fais fab (Kw)	Kev sib hloov ceev (r/min)	Ntim Flow(m³/h)	Tag nrho siab (paj)
2.8A	1.5	2900	1131-2356	994-606
3.2A	2.2	2900	1688-3517	1300-792
3.2A	1.1	1450	844-1758	324-198
3.6A	3	2900	2664-5268	1578-989
3.6A	1.1	1450	1332-2634	393-247
4A	5.5	2900	4012-7419	2014-1320
4A	1.1	1450	2006-3700	501-329
4.5A	7.5	2900	5712-10562	2554-1673
4.5A	1.1	1450	2856-5281	634-416
5A	15	2900	7728-15455	3187-2019
5A	2.2	1450	3864-7728	790-502
6A	4	1450	6677-13353	1139-724
6A	1.5	960	4420-8841	498-317
6C	15	2240	10314-20628	2734-1733
	11	2000	9209-18418	2176-1380
	7.5	1800	8288-16576	1760-1116
	5.5	1600	7367-14734	1389-881
	3	1250	5756-11511	846-537
	2.2	1000	4605-9209	541-344
	1.1	800	3684-7367	346-220
7C	18.5	1800	13161-26322	2395-1519
	15	1600	11698-23397	1890-1199
	11	1450	10602-21204	1553-984
	7.5	1250	9140-18279	1151-731
	5.5	1120	8189-16378	924-586
	4	1000	7312-14623	736-468
8C	37	1800	28105-36427	2920-2302
	30	1800	19646-25240	3143-3032
	22	1600	17463-22435	2478-2390
	11	1250	13643-25297	1507-1106
	7.5	1120	12224-15705	1209-1166
	5.5	1000	10914-14022	963-929
	5.5	900	14052-18213	725-572
	3	800	8732-16190	615-452
	2.2	710	7749-11085	485-450
10C	37	1250	34863-48797	2373-1877
	30	1120	31237-43722	1902-1505
	18.5	1000	27890-39038	1514-1199
	15	900	25101-35134	1225-970
	11	800	22312-31230	967-766
	7.5	710	19802-27717	761-603
	5.5	630	17571-24594	599-475
12C	75	1120	53978-75552	2746-2172
	55	1000	63953-67457	1859-1729
	37	900	43375-60712	1767-1399
	30	800	38556-53966	1395-1104
	18.5	710	34218-47895	1097-869
	15	630	30362-42498	863-684
	11	560	31774-37776	646-540
	7.5	500	24097-33728	543-430
12C	110	1000	76535-107124	2985-2361
	75	900	68881-96412	2412-1908
	55	800	61228-85699	1903-1506
	37	710	54340-76058	1497-1185
	30	630	48217-67488	1177-932
	18.5	560	42859-59990	929-736
	15	500	38267-53562	741-587
	11	450	34441-48206	599-474
	7.5	400	30614-42850	474-375
	5.5	355	27170-38029	372-295

Tom qab li 20 xyoo kev, kiv cua JN tam sim no yog ib yam ntawm cov kev 4-72 rov qab nkhaus impeller stainless hlau muaj chaw dim pa centrifugal blower ntxuam manufacturers muag thiab lwm tus neeg nyob hauv Suav teb. Yog hais tias koj xav wholesale lub zoo chaw dim pa khoom hauv Suav teb, txais tos hu peb koom xwm rau cov khoom siv.

Cim npe nrov: 4-72 impeller rov qab nkhaus hlau stainless muaj chaw dim pa centrifugal blower kiv cua kom muag khoom, Suav teb, hoobkas, lwm tus neeg, manufacturers, lag luam wholesale, hauv Suav teb
